SH Series 3000VA 24v Pure sine wave +4 batteries &2 battery cabinets

Product Details

48v Dc input-230v AC output

3200 watt continuous power
8x 105A/hr batteries & 4 cabinets + cables

Watt	4 batt	8 batt
200	10 hrs	20 hrs
300	6,72 hrs	13,44 hrs
400	5 hrs	10 hrs
600	3,36 hrs	6,72 hrs
800	2,5 hrs	5 hrs
1000	2 hrs	4 hrs
1200	1,68 hrs	3,36 hrs
1400	1,44 hrs	2,88 hrs
1600	1,26 hrs	2,52 hrs
1800	1,12 hrs	2,24 hrs
2000	1 hrs	2 hrs
2200	0,92 hrs	1,83 hrs
2400	0,84 hrs	1,68 hrs

To use different power & battery settings use the calculator below

INTRODUCTION
The SH series is the ultimate sine wave inverter for houses, offices, security, factories and recreational use. These units can be used for anything within its specifications. Pure sine wave output makes this unit a must have for equipment where power outages range from 2 – 12 hours.

APPLICATION
PC’s, TV’s, Fans, Electric Drills, Refrigerators, Recorders, Water Machines, Lighting, Switchboards, Servers and other Home Appliances and Office Equipment

FEATURES

Intelligent long run model
Fully digitized microprocessor controlled
Wide input voltage window
Energy saving function with UPS green mode
Short circuit and overload protection
Cold start
Intelligent battery management
Compatible with generators
High inrush capabilities
Bypass output

(optional connected through sub DB)

(Optional Connected to Main DB)
